Shelly Wave works on Z-Wave
Universally compatibleYou can integrate Shelly directly with virtually every smart home hub, voice assistant, open source platform, or premium control system. |
![]() |
||||
![]() |
![]() |
||||
![]() |
![]() |
||||
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
Universally compatibleYou can integrate Shelly directly with virtually every smart home hub, voice assistant, open source platform, or premium control system. |
|
![]() |
|
![]() |
|
![]() |
|
![]() |
|
![]() |
|
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
Specifications
| PHYSICAL | |
|---|---|
| Size (HxWxD) | 38x84x52 mm / 1.5x3.3x2.0 in |
| Weight | 70 g / 2.47 oz |
| Compatible sockets | NEMA 5-15 (Type B) |
| Compatible plugs | NEMA 1-15 (Type A) and NEMA 5-15 (Type B) |
| Shell material / color | Plastic / White |
| ENVIRONMENTAL | |
| Ambient working temperature | -20°C to 40°C / -5°F to 105°F |
| Humidity | 30% to 70% RH |
| Max. altitude | 2000 m / 6562 ft |
| ELECTRICAL | |
| Power supply | 120 V AC +/-10%, 60 Hz |
| Power consumption | < 0.3 W |
| Max. switching voltage AC | 140 V |
| Max. switching current AC | 15 A |
| Power measurement | Yes |
| Overheating / overcurrent / overvoltage protection | Yes / Yes / Yes |
| Z-WAVE | |
| Long range distance | Up to 80 m / 262 ft indoors, 1000 m / 3281 ft outdoors |
| Long range frequency | 912 MHz |
| Mesh distance | Up to 40 m / 131 ft indoors |
| Mesh frequency | 908.4 MHz |
| Z-Wave repeater (mesh) | Yes |
| CPU | Z-Wave S800 |
