No hub required, Universally compatibleShelly Products can be controlled locally, directly and without a hub through your smartphone/table with Shelly App - no hub or other equipment needed. Enable cloud feature and get remote control from anywhere. At the same time, you can integrate Shelly directly with virtually every smart home hub, voice assistant, open source platform, or premium control system. |
![]() |
||||
![]() |
![]() |
||||
![]() |
![]() |
||||
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
No hub required, Universally compatibleShelly Products can be controlled locally, directly and without a hub through your smartphone/table with Shelly App - no hub or other equipment needed. Enable cloud feature and get remote control from anywhere. At the same time, you can integrate Shelly directly with virtually every smart home hub, voice assistant, open source platform, or premium control system. |
|
![]() |
|
![]() |
|
![]() |
|
![]() |
|
![]() |
|
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
![]() |
Specifications
| PHYSICAL | |
|---|---|
| Size (HxWxD) | 37x42x16 mm / 1.46x1.65x0.63 in |
| Weight | 30 g / 1.06 oz |
| Conductor cross section | 0.5 to 4 mm2 / 20 to 11 AWG |
| Conductor stripped length | 6 to 7 mm / 0.24 to 0.28 in |
| Mounting | Wall box |
| Shell material / color | Plastic / Black |
| ENVIRONMENTAL | |
| Ambient working temperature | -20°C to 40°C / -5°F to 105°F |
| Humidity | 30% to 70% RH |
| Max. altitude | 2000 m / 6562 ft |
| ELECTRICAL | |
| Power supply | 110-240 V AC / 24 V DC +/-10% |
| Power consumption | < 1.4 W |
| OUTPUT CIRCUITS RATINGS | |
| Max. switching voltage | 240 V AC / 30 V DC |
| Max. switching current AC | 10 A per channel, 16 A total, 18 A total peak |
| Max. switching current DC | 10 A |
| SENSORS, METERS | |
| Voltmeter / Ammeter (AC) | Yes / Yes |
| Internal-temperature sensor | Yes |
| WI-FI | |
| Protocol | 802.11 b/g/n |
| Range | 30m/100ft indoors, 50m/160ft outdoors |
| BLUETOOTH | |
| Protocol | 4.2 |
| Range | 10m/33ft indoors, 30m/100ft outdoors |
| MICROCONTROLLER UNIT | |
| CPU / Flash | ESP-Shelly-C38F / 8 MB |
| FIRMWARE CAPABILITIES | |
| Schedules | 20 |
| Webhooks (URL actions) | 20 with 5 URLs per hook |
| Scripting | Yes |
| MQTT | Yes |
